Fluorescent Immunoassay quantitative POCT analyzer

Introduction：Shanghai Xiongtu is the first in the field of food safety to combine time-resolved fluorescence immunoassay technology with POCT concept, forming time-resolved fluorescence immunoassay quantitative POCT technology products. The products have strong specificity, high sensitivity, good stability, simple and convenient operation, and the detection types cover rice, wheat, corn, peanuts and their deep processed products and by-products; DDGS、 Soybean meal, bran and other feed raw materials and feed products; Animal derived samples such as meat, eggs, milk, urine, and serum. The pre-processing is simple and the detection time is short.

【Product Attributes】

Model/Specification: XT8201A Power Supply: 220V to 12V/4A

Basic Dimensions: 320×245×165 (Length×Width×Height, Unit: mm) Overall Weight: 2.5KG

Display: 7-inch Touch Color Screen Excitation Light Source: LED

Central Wavelength of Excitation Spectrum: λ0=365nm Central Wavelength of Reception Spectrum: λ1=610nm

Interfaces: RS232 Serial Port, USB Port, Network Port Print Function: Built-in Thermal Printer

Repeatability: CV≤1% Stability: CV≤1%

【Application Scope】

It has broad application prospects in the fields of mycotoxin detection, drug residue detection, illegal additive detection, etc.

★ High accuracy, small error (δ＜0.05%), good repeatability (CV<1%);

★ Built-in quantitative calculation formula to automatically calculate the final qualitative and quantitative results;

★ Unique excitation light system and efficient optical filter system;

★ Built-in automatic barcode and QR code recognition system;

★ Verified by multiple authoritative departments for performance;

★ Flexible sample numbering, optional automatic numbering and custom numbering;

★ Standard curve automatically saved, information automatically read;

★ Simple operation, fast reading, high efficiency, low cost;

★ Supports intelligent IoT function and built-in printing function;

★ Free on-site training and lifetime free software upgrades.

★ Feed processing enterprises;

★ Livestock, poultry and aquatic breeding enterprises;

★ Processing enterprises of grain, oil, rice, flour and wine, as well as their raw material warehousing and circulation enterprises;

★ Chinese herbal medicine processing enterprises and their raw material warehousing and circulation enterprises;

★ Large supermarkets and agricultural markets;

★ Central kitchens;

★ Government-related units such as grain bureaus;

★ Entry-exit inspection departments;

★ Veterinary stations;

★ Supervision offices;

★ Quality inspection institutes, etc.
